Name: Elite Series Body Mounted Spare Tire Carrier - Jeep TJ / LJ
Brand: CavFab
SKU: CF226
Price: 639.99 USD
Availability: InStock

Elite Series Body Mounted Spare Tire Carrier - Jeep TJ / LJ

Elite Series Body Mounted Spare Tire Carrier (TJ / LJ) - CavFab

$639.99

Wheel Bolt Pattern

5x4.5 Bolt Pattern 1/2"-20 Stud (Stock TJ)

5x5 Bolt Pattern 1/2"-20 Stud (JK)

5x5 14mmx1.5 Stud (JL)

8x6.5 Bolt Pattern 9/16"-18 Stud

8x170 Bolt Pattern 14x1.5 Stud

License Plate Relocation Bracket

No License Plate Relocation Bracket

Add License Plate Relocation Bracket

[{"id":44660380893436,"title":"5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ) \/ No License Plate Relocation Bracket","option1":"5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ)","option2":"No License Plate Relocation Bracket","option3":null,"sku":"CF226","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ) \/ No License Plate Relocation Bracket","public_title":"5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ) \/ No License Plate Relocation Bracket","options":["5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ)","No License Plate Relocation Bracket"],"price":63999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44660380926204,"title":"5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ) \/ Add License Plate Relocation Bracket","option1":"5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ)","option2":"Add License Plate Relocation Bracket","option3":null,"sku":"CF227","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ) \/ Add License Plate Relocation Bracket","public_title":"5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ) \/ Add License Plate Relocation Bracket","options":["5x4.5 Bolt Pattern 1\/2\"-20 Stud (Stock TJ)","Add License Plate Relocation Bracket"],"price":70999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44660375322876,"title":"5x5 Bolt Pattern 1\/2\"-20 Stud (JK) \/ No License Plate Relocation Bracket","option1":"5x5 Bolt Pattern 1\/2\"-20 Stud (JK)","option2":"No License Plate Relocation Bracket","option3":null,"sku":"CF228","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 5x5 Bolt Pattern 1\/2\"-20 Stud (JK) \/ No License Plate Relocation Bracket","public_title":"5x5 Bolt Pattern 1\/2\"-20 Stud (JK) \/ No License Plate Relocation Bracket","options":["5x5 Bolt Pattern 1\/2\"-20 Stud (JK)","No License Plate Relocation Bracket"],"price":63999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44660375355644,"title":"5x5 Bolt Pattern 1\/2\"-20 Stud (JK) \/ Add License Plate Relocation Bracket","option1":"5x5 Bolt Pattern 1\/2\"-20 Stud (JK)","option2":"Add License Plate Relocation Bracket","option3":null,"sku":"CF229","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 5x5 Bolt Pattern 1\/2\"-20 Stud (JK) \/ Add License Plate Relocation Bracket","public_title":"5x5 Bolt Pattern 1\/2\"-20 Stud (JK) \/ Add License Plate Relocation Bracket","options":["5x5 Bolt Pattern 1\/2\"-20 Stud (JK)","Add License Plate Relocation Bracket"],"price":70999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44677876875516,"title":"5x5 14mmx1.5 Stud (JL) \/ No License Plate Relocation Bracket","option1":"5x5 14mmx1.5 Stud (JL)","option2":"No License Plate Relocation Bracket","option3":null,"sku":"CF230","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 5x5 14mmx1.5 Stud (JL) \/ No License Plate Relocation Bracket","public_title":"5x5 14mmx1.5 Stud (JL) \/ No License Plate Relocation Bracket","options":["5x5 14mmx1.5 Stud (JL)","No License Plate Relocation Bracket"],"price":63999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44677876908284,"title":"5x5 14mmx1.5 Stud (JL) \/ Add License Plate Relocation Bracket","option1":"5x5 14mmx1.5 Stud (JL)","option2":"Add License Plate Relocation Bracket","option3":null,"sku":"CF231","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 5x5 14mmx1.5 Stud (JL) \/ Add License Plate Relocation Bracket","public_title":"5x5 14mmx1.5 Stud (JL) \/ Add License Plate Relocation Bracket","options":["5x5 14mmx1.5 Stud (JL)","Add License Plate Relocation Bracket"],"price":70999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44660375388412,"title":"8x6.5 Bolt Pattern 9\/16\"-18 Stud \/ No License Plate Relocation Bracket","option1":"8x6.5 Bolt Pattern 9\/16\"-18 Stud","option2":"No License Plate Relocation Bracket","option3":null,"sku":"CF232","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 8x6.5 Bolt Pattern 9\/16\"-18 Stud \/ No License Plate Relocation Bracket","public_title":"8x6.5 Bolt Pattern 9\/16\"-18 Stud \/ No License Plate Relocation Bracket","options":["8x6.5 Bolt Pattern 9\/16\"-18 Stud","No License Plate Relocation Bracket"],"price":63999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44660375421180,"title":"8x6.5 Bolt Pattern 9\/16\"-18 Stud \/ Add License Plate Relocation Bracket","option1":"8x6.5 Bolt Pattern 9\/16\"-18 Stud","option2":"Add License Plate Relocation Bracket","option3":null,"sku":"CF233","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 8x6.5 Bolt Pattern 9\/16\"-18 Stud \/ Add License Plate Relocation Bracket","public_title":"8x6.5 Bolt Pattern 9\/16\"-18 Stud \/ Add License Plate Relocation Bracket","options":["8x6.5 Bolt Pattern 9\/16\"-18 Stud","Add License Plate Relocation Bracket"],"price":70999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44660375453948,"title":"8x170 Bolt Pattern 14x1.5 Stud \/ No License Plate Relocation Bracket","option1":"8x170 Bolt Pattern 14x1.5 Stud","option2":"No License Plate Relocation Bracket","option3":null,"sku":"CF234","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 8x170 Bolt Pattern 14x1.5 Stud \/ No License Plate Relocation Bracket","public_title":"8x170 Bolt Pattern 14x1.5 Stud \/ No License Plate Relocation Bracket","options":["8x170 Bolt Pattern 14x1.5 Stud","No License Plate Relocation Bracket"],"price":63999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44660375486716,"title":"8x170 Bolt Pattern 14x1.5 Stud \/ Add License Plate Relocation Bracket","option1":"8x170 Bolt Pattern 14x1.5 Stud","option2":"Add License Plate Relocation Bracket","option3":null,"sku":"CF235","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Elite Series Body Mounted Spare Tire Carrier - Jeep TJ \/ LJ - 8x170 Bolt Pattern 14x1.5 Stud \/ Add License Plate Relocation Bracket","public_title":"8x170 Bolt Pattern 14x1.5 Stud \/ Add License Plate Relocation Bracket","options":["8x170 Bolt Pattern 14x1.5 Stud","Add License Plate Relocation Bracket"],"price":70999,"weight":31751,"compare_at_price":null,"inventory_management":null,"barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}]

Product Description

PRODUCT DESCRIPTION

Note: This will not fit with the factory light position. Modifications or aftermarket lights are required.

Introducing the CavFab TJ/LJ Elite Series Body-Mounted Spare Tire Carrier! Built from laser-cut 3/16", 1/4", and 3/8" American steel with precision welds, this tire carrier is engineered to handle up to a 42" tire and extreme off-road demands. Strength, durability, and performance in one rugged design.

VEHICLE FITMENT

1997 - 2006 Jeep Wrangler TJ / LJ

FEATURES

Designed, Engineered, Tested, and Built in the USA
CNC Laser Cut & Formed 3/16" , 1/4", and 3/8" American Steel
Oilite Bronze Bushings For Lifetime Maintenance Free Use
Adjustable Tire Mount For a Variety Of Tire Sizes
Ability To Hold a 42" Tire Without Rattling (About 4" adjusting up and down)
Additional tie in to the cage included for even more security
With our corner armor and the included tie-in, we're able to get a 42" tire mounted (and can still do so with the stock Bumper)
Optional License Plate Relocation Bracket Available
Ships Raw Steel
Direct Bolt On Install
Accommodates The Following Bolt Patterns
5x4.5 with 1/2-20 Stud (TJ Stock OEM Axle)
5x5 1/2-20 Stud (JK axle)
5x5 14mmx1.5 Stud (JL Axle)
8x6.5, and 8x170 Bolt Patterns (1 Ton Axles)
No Cutting, No Drilling (Update, 11/6/23, We have found there are some models that have weld-in nuts on the upper hinge, which would need to be removed to utilize the tie-in)

WHATS INCLUDED

TJ / LJ Elite Series Body Mounted Spare Tire Carrier Kit
All Mounting Hardware
Optional License Plate Relocation Bracket Available

NOTES

If you have a non-stock Cage, this should still fit if it is in the same placement. If the cage is any further forward or back, the tie-in will not work. Closer to the gate will still fit with modification, but further from the gate will not fit.
Past 37" we would definitely recommend having a corner armor for safety. Ours can be purchased at these links:

Product Specifications

No file available

Assembly Instructions

No file available

Here at CavFab we utilize UPS Ground and USPS Priority shipping. Once your order ships, you’ll receive an email with your shipping details and tracking number. This way, you can follow your order until it arrives at your door. If you have any questions about your shipment, feel free to reach out to us at info@cavfab.com.

Have questions about this product? We’re here to help! Whether you need more details, advise on compatibility, or assistance in deciding if this is the right fit for your build, reach out to us. Email us anytime at info@cavfab.com, and our team will get back to you with the answers you need to make your purchase with confidence.

100% MADE IN THE USA

Our products are fabricated by a world class team of American craftsmen.
